Harnessing the Power of the ESP32-S3: A Look at Copperhill’s CAN FD Development Board
Posted by on
In the evolving landscape of IoT, industrial automation, and automotive communication, the demand for a versatile, wireless-enabled microcontroller with CAN bus capabilities has never been greater. Copperhill Technologies rises to the occasion with its latest innovation—a development board based on the ESP32-S3-WROOM-1-N8R8, engineered to support both Classical CAN and CAN FD protocols.
At the heart of the board lies the ESP32-S3, a powerful dual-core system-on-chip microcontroller from Espressif. Designed with performance and efficiency in mind, the ESP32-S3 features an Xtensa® LX7 processor running at up to 240 MHz. It includes a hardware floating point unit, making it ideal for real-time calculations, sensor fusion, and signal processing tasks.
What truly sets this board apart from previous ESP32 offerings is its native USB support. Unlike the traditional setup where USB-to-UART converters are required, the ESP32-S3 integrates a full-speed USB OTG peripheral. This allows direct USB connectivity for programming, debugging, and communication without intermediary chips—simplifying hardware design and improving reliability. Developers can now use the USB port as a virtual COM port, an HID device, or even as a Mass Storage device, depending on their application needs.
From a connectivity standpoint, the board makes full use of the ESP32-S3’s advanced wireless features. It supports Wi-Fi 802.11 b/g/n for robust internet connectivity and includes Bluetooth 5, Bluetooth Low Energy (BLE), and Bluetooth Mesh—offering maximum flexibility for wireless sensor networks, smart home applications, and BLE-based communication protocols.
However, what truly broadens the board’s appeal is its dual CAN bus functionality. The ESP32-S3’s internal controller supports Classical CAN natively. But for developers and engineers working with modern automotive and industrial systems that require higher data throughput and extended data frames, the board includes a Microchip MCP2518FD chip to handle CAN FD. This external controller is interfaced via SPI and enables seamless integration with networks already moving to the newer, faster CAN FD standard.
On the hardware side, the board is robust and well-equipped for professional deployment. It offers 8 MB of flash memory alongside 8 MB of PSRAM, providing ample space for storing application code, buffer data, and even machine learning models if needed. Powering the device is simple thanks to an onboard SMPS (switched-mode power supply) that accepts input voltages between 7V and 24V. Built-in reverse polarity protection adds an extra layer of durability for field installations.
Ease of use has also been considered in the design. A USB-C port is provided for both power and programming, and the board includes clearly labeled boot and reset buttons. A user-configurable RGB LED offers simple visual feedback during development. There's also an I²C connector onboard, enabling rapid attachment of external sensors or peripherals.
As edge computing becomes more prevalent, developers are increasingly turning to platforms like the ESP32-S3 not just for communication, but also for onboard processing. The ESP32-S3 supports AI acceleration, and this board is more than capable of running lightweight machine learning models using frameworks like tinyML. This opens the door to intelligent IoT devices that can process data locally—minimizing latency, bandwidth usage, and reliance on cloud services.
In real-world terms, this development board can serve as the backbone of a wide array of applications. It’s ideal for creating a smart vehicle telemetry system that wirelessly transmits CAN data to the cloud. It can function as a dual CAN gateway in industrial settings, or as a powerful Wi-Fi and BLE-enabled sensor hub. With its USB capabilities, it can even double as a diagnostic tool when connected to a host system.
Overall, Copperhill Technologies’ ESP32-S3 board is more than just another development kit. It’s a compact, full-featured platform built around a cutting-edge microcontroller, ready to tackle the complexities of modern embedded systems. Whether you're a professional engineer designing automotive tools or an IoT hobbyist pushing the limits of what's possible, this board provides the tools, flexibility, and performance to bring your vision to life.
For more information or to order the board, visit the official product page on Copperhill Technologies’ website.
