LIN Bus Slave RGB LED Breakout Board

Free Shipping Within the United States!

• Further Shipment Information & Options...

This board is an RGB LED breakout board based the On Semi NCV7430 IC chip. The breakout board is controlled via a LIN-Bus connection, and it is ideal for use as a LIN Bus slave to test your LIN master software.

Features

• 3 Independent LED Current Regulators
• LED Currents Adjustable with External Resistors
• LIN Physical Layer according to LIN 2.1/ SAE J2602
• Overcurrent Detection
• Short Circuit Detection to GND and VBB
• Open LED Detection
• Connection via two 3way 0.1" header which can be used for daisy chaining

Documents

• Schematic...
• NCV7430 datasheet...
• Teensy 3.2 LIN master demo code...

 The photo below demonstrates using the NCV7430 LIN-Bus breakout board in combination with the Teensy 3.2 LIN Bus master (not included).
