PCI Express Mini Card with 2 CAN or 2 CAN FD Interfaces

Posted by Industry News on

esd electronics PCI Express Mini Card with 2 CAN or 2 CAN FD Interfaces

esd electronics announces their CAN-PCIeMini/402-2(-FD), a PCI Express Mini Card with 2 CAN or 2 CAN FD (Flexible Data Rate) Interfaces. he CAN-PCIeMini/402-2 is an add-in PCI Express Full-Mini Card, featuring two electrically isolated CAN High-Speed interfaces. The PCI Express® Mini Card CAN-PCIeMini/402-2-FD comes with two CAN FD interfaces. An optional adapter offers a DSUB9 connector and on-board CAN termination.

The independent CAN nets are driven by the ISO 16845:2004 certified esdACC (esd Advanced CAN Core) implemented in the Altera FPGA. The FPGA supports bus mastering (first-party DMA) to transfer data to the host memory. This results in a reduction of overall latency on servicing I/O transactions in particular at higher data rates and a reduced host CPU load.

Due to the usage of MSI (Message Signaled Interrupts) the CAN-PCIeMini/402-2(-FD) can be operated for example in Hypervisor environments. The CAN-PCIeMini/402-2(-FD) provides high resolution 64-bit hardware timestamps for CAN messages.


  • 2 CAN (FD) interfaces according to ISO 11898-2
  • Bus mastering and local data management by FPGA
  • PCIe® Mini interface according to Mini Card Electromechanical Spec. R1.2
  • Supports MSI (Message Signaled Interrupts)
  • Full-Mini Card (Type F2) form factor

Software Support

  • Software drivers for Windows® and Linux® included free of charge
  • Optional CAN layer 2 software drivers for real-time operating systems
  • CANopen®, J1939 and ARINC 825 protocol libraries for Classical CAN applications
  • ISO 16845:2004 certified esd Advanced CAN Core (esdACC) technology
  • High resolution hardware timestamps
