PCI-Express (PCIe) CAN Bus/LIN Bus Network Interface For Accessing CAN Bus And LIN Bus Networks

Posted by Industry News on

Vector VN1530 PCI-Express (PCIe) CAN Bus - LIN Bus Network Interface For Accessing CAN Bus And LIN Bus Networks

Vector announced its newest PCIe network interface board, the VN1530, supporting four onboard communication ports and two additional piggybacks for increased flexibility. The system supports channel combinations for interfacing to CAN BusCAN FDLIN Bus, and other network technologies. The board addresses the growing demand for more channels, especially at test benches, test PCs and in-rack use.

The product comes with functions for analysis, simulation, and testing of ECUs, sensors, and gateways. Among many other features, these functions allow bus simulation, measurement of communication data, end-of-line tests, and flashing. A transport protocol accelerator is also available for CAN Bus applications. Developers can use the device for purposes such as performing extended LIN Bus stress tests, e.g., LIN 2.1 conformance tests.

For users of multiple devices, the VN1530 offers the advantage of allowing synchronization between multiple devices and different bus systems such as CAN Bus, CAN FD, LIN Bus, FlexRay, Most, and Ethernet. Additional XL driver libraries support proprietary customer applications. Users profit from the product's support of 100 % bus load on all channels, minimal latency times and low CPU utilization of the host.

More Information...


Isolated LIN Bus Breakout Board

Isolated LIN Bus Breakout Board

This is an isolated LIN Bus breakout board using the TJA1028 and MAX12931 ICs.

Features

  • LIN 2.0/2.1/2.2 compliant
  • SAE J2602 compliant
  • Internal LIN slave termination resistor
  • Master option via jumper setting
  • Robust ESD performance; 8 kV according to IEC61000-4-2 for pins LIN and VBAT
  • LIN pin short-circuit proof to battery and ground
  • K-line compatible
  • Galvanic Isolation of Digital Signals
    • Withstands 3kVRMS for 60s
    • Continuously Withstands 445VRMS (VIOWM)
    • Withstands ±10kV Surge Between GNDA and GNDB with 1.2/50μs Waveform
    • High CMTI (50kV/μs, typ)
