Testing The SAE J1939 to RS232 & USB Gateway By Copperhill Technologies

Posted by Wilfried Voss on

SAE J1939 to RS2322-USB Gateway Test Setup

In this post, I will demonstrate the test setup of our SAE J1939 to RS232 & USB Gateway. The JCOM.J1939.SER gateway is a high-performance, low-latency, serial vehicle network adapter for SAE J1939 applications. It allows any host device with an RS232 or USB port to monitor SAE J1939 data traffic and communicate with the SAE J1939 vehicle network. An SAE J1939 cable, suited for a 9-pin Deutsch connection, is included with the gateway.

In order to simulate SAE J1939 data traffic, rather than connecting to a real-world diesel engine, we utilize our  SAE J1939 ECU Simulator Board With USB Port

In fact, both devices are based on the same hardware concept and firmware, however, with slight differences. The J1939-to-USB gateway is designed for simulation and monitoring of SAE J1939 data traffic under lab conditions. The RS232-to-J1939 gateway is designed for operation connected to a diesel engine's network in order to monitor SAE J1939 data traffic.

Moreover, both devices can be controlled per our free-of-charge JCOM1939 Monitor Software.

Two Instances of JCOM1939 Monitor

The above image demonstrate the operation of two instances of the Windows software, one connected to COM Port 3 (USB), the other connected to COM Port 27 (RS232).

Both devices can also operate when connected to other devices such as embedded systems or Linux machines. The serial protocol (identical whether it's the USB or RS232 gateway) is documented in detail, and there are programming samples for Linux, Raspberry Pi, and Windows.
